| Specifications | |
| Main IC | T20 |
| Image Sensor | 1/4.5-inch cmos sensor |
| Display Resolution | 720P (1280*720P) /1MP |
| Mini. Illumination | 2 Lux (with infrared led on) |
| Focal Length | 4mm |
| Viewing Angle(D/H/V) | 60°/50°/30° |
| LED | Dual light sources; 2 white lights, 8 850nm LED infrared distance up to 6 meters |
| Day night mode | IR cut filter with auto switch |
| Image Compression | H.264 |
| Mirrow flip | Support |
| View mode | HD & SD |
| Audio | Built-in Mic & Speaker |
| Supported protocols | TCP/IP, RTSP, DHCP,NTP,ONVIF,UDP/IP,HTTP |
| Dynamic DNS | Support |
| Stream | Dual Stream |
| wireless | IEEE802.11b/g/n 150Mbps |
| Frequency | 2.4G |
| Antennas | built-in |
| Antenna gain | 3dB |
| Wireless Security | 64/128-bit WEP, WPA/WPA2,WPA-PSK/WPA2-PSK |
| Range | Horizontal: 350 degree |
| Vertical: 70 degree | |
| Remote management | Yes APP remote |
| Multiple user management | Support (in app) |
| Split screen view | Support (in app) |
| Mobile app | IOS & Android |
| Motion detection | Support |
| Notification method | Mobile Push |
| Remote Access | P2P |
| LED indicator Light | N/A |
| Storage | Micro SD Card up to 128GB |
| Cloud | Support cloud storage |
| Certifications | CE,FCC |
| Alexa | Support |
| Google Home | Support |
| Bare metal weight(g) | 178g |
| Bare metal size | 118*80*80mm |
| Bare package weight (g) | 293g |
| Bare metal package size | 115*85*125mm |
| Packing Quantity | 1=20 |
| Maximum power consumption | <4.4w |
| Power parameters | 5V1A Micor USB |
| Working Temperature | -10°C ~ 50°C |
| Working Humidity | 20% ~ 95% non-condensing |
